NOU
MB Asrock B860 LIVEMIXER WIFI LGA1851
1.133,99 RON
(TVA inclus)
937,18 RON
(fara TVA)
Costurile de livrare nu sunt incluse
Cum te putem ajuta?
Descriere
Placa de Baza ASROCK B860 LIVEMIXER WIFI LGA1851, 4x DDR5, 1x HDMI 1x Intel Thunderbolt, 2x PCIE x16, 4x M.2, 4x SATA 6GB/s, ATX
Detalii
SKU
B860 LIVEMIXER WIFI
Categorii
Brand
Product colour
Black
Ethernet LAN
Yes
Wi-Fi
Yes
Processor manufacturer
Intel
Bluetooth version
5.3
Ethernet LAN (RJ-45) ports
1
USB connector type
USB Type-A, USB Type-C
Audio output channels
7.1 channels
HDCP
Yes
Windows operating systems supported
Windows 11 x64
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
6
DVI-D ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 2.0 ports quantity
6
Memory channels
Dual-channel
Maximum internal memory
256 GB
Top Wi-Fi standard
Wi-Fi 6E (802.11ax)
LAN controller
Dragon RTL8125BG
Motherboard chipset
Intel B860
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
Number of SATA III connectors
4
Number of storage drives supported
7
PCI Express x16 (Gen 4.x) slots
1
Memory slots type
DIMM
PCI Express x16 (Gen 5.x) slots
1
S/PDIF out port
Yes
Headphone outputs
1
VGA (D-Sub) ports quantity
0
Microphone in
Yes
Component for
PC
Maximum resolution
7680 x 4320 pixels
Parallel processing technology support
Not supported
BIOS type
UEFI AMI
BIOS memory size
256 Mbit
Number of M.2 (M) slots
3
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
2280
2nd M.2 largest key size
2280
Motherboard chipset family
Intel
Motherboard form factor
ATX
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
CPU fan connector
Yes
EPS power connector (8-pin)
Yes
RGB LED pin header
Yes
12V power connector
Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors
3
USB 2.0 connectors
2
Number of chassis fan connectors
5
Number of EPS power connectors (8-pin)
2
Number of CPU fan connectors
2
Number of water pump connectors
1
Number of RGB LED pin headers
1
Number of memory slots
4
Unbuffered memory
Yes
Supported memory types
DDR5-SDRAM
ECC сompatibility
Non-ECC
Ethernet interface type
2.5 Gigabit Ethernet
Antenna included
Yes
Processor socket
LGA 1851 (Socket V1)
Supported processor sockets
LGA 1851
Compatible processor series
Intel Core Ultra (Series 2)
WiFi-AP antenna jack
2
RAID support
Yes
Supported storage drive types
HDD & SSD
Supported storage drive interfaces
PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels
0, 1, 5, 10
PCI-Ex1
0
RAM-Slots
4
MB-Socket
AM5
PCI-Ex16
2
MB-Format
ATX
USB3
4-8
Onboard-CPU
No
PCI
0
3rd M.2 largest key size
2280
TPM connector
Yes
Thunderbolt ports quantity
1
Bluetooth
Yes
